Simex Crusher Buckets for skid steer loaders

CB2000

Simex Crusher Buckets for skid steer loaders

$41,565.00

DESCRIPTION
SPECS

Crusher Buckets Front Mount

Designed for reduce the volume of aggregates directly on site, the CB crusher buckets for loaders and skid steers give optimal performance when working with iron, rock, soil and deformable parts, and wet or humid materials, thanks to the rotor system.

Ideal for crushing reinforced concrete and demolition waste. The exceptional cutting force allows any material to be crushed, without suffering the presence of rebar in it. The rotor with teeth is activated by high-displacement radial piston hydraulic motors in direct drive.

Advantages

High cutting force
Simple, quick tool replacement
No vibrations
Safe coupling and decoupling
Replaceable blades for output size variation
Lightweight frame

Features

Simex CB crusher buckets are available in 4 models (CB900-1200-1500-2000) for skid steers and front loaders.

High cutting force

The exceptional cutting force allows any material to be crushed. The rotor with teeth is activated by high-displacement radial piston hydraulic motors in direct drive.

Ideal on concrete and waste material

Simex CB front crusher buckets are ideal for crushing and reduct waste material deriving from demolition, directly on site.

Easy tools replacement

The crushing tools easily interlock to the shaft with no weldings and are easily replaceable on site with no downtime due to long technical interventions.

unaffected by the presence of rebar

Crusher buckets can process reinforced concrete, unaffected by the presence of rebar in it.

Applications

The Simex CB crusher buckets for skid steers and front loaders are ideal when working on those sites where, due to space constraints or technical requirements, other machines would not be able to work, allowing to crush different types of materials such as reinforced concrete, bricks, wood, plasterboard, bricks and other aggregates resulting from demolition or construction.

crushing demolition waste

Processing waste material from demolition and construction, the CB crusher bucket for front loaders finds its perfect situation. Instead of outsourcing the disposal processes, the operator can manage the volumetric reduction of the aggregates directly on site, producing a recycled material that can be used, for example, as stabilized aggregate for building development or in the road sector for the realization of embankments, back-fillings or yards.

MODELS AND TECHNICAL DATA	°°°	CB 900	CB 1200	CB 1500	CB 2000
Total width	mm	1400	1500	1700	1900
.	inch	55	60	67	75
Rotor width	mm	700	840	965	1100
.	inch	27	33	38	43
Bucket capacity (SAE)	m³	0,30	0,45	0,55	0,75
.	yd³	0,40	0,60	0,70	1,00
Number of teeth	n°	5	6	7	8
Bucket weight empty	kg	570	760	950	1150
.	lbs	1250	1670	2090	2530
Bucket weight at full load (1)	kg	900	1200	1500	2000
.	lbs	1980	2640	3300	4400
Required oil flow	l/m	40-80	70-150	70-150	70-150
.	gpm	11-21	18-40	18-40	18-40
Max. required oil pressure	BAR	300	350	350	350
.	psi	4400	5100	5100	5100
