E01 TORO
ALLIED Excellence Line Compact range hammer for mini loader
$7,750.00 - $9,650.00
Revised 3/24
RAMMER
EXCELLENCE LINE
COMPACT RANGE HAMMER
Rammer’s world-renowned Excellence line completes
with the Compact range hammers, which offer versatile,
reliable solutions for construction applications
THE MOST EFFICIENT OPERATIONS FEATURES:
- CBE enables plug-and-play installation
- High uptime and easy maintenance based on membrane accumulator
- Compact, right size for the job – optimized fuel consumption
- Extremely good power to weight ratio
| ALLIED HAMMER MODEL | E01 | E02 | E04 |
| CARRIER LBS. RANGE | 900-4200 | 1500-1600 | 2600-8800 |
| CARRIER GPM RANGE | 2.6-8.2 | 4.0-13.2 | 5.3-16.4 |
| MAX PRESSURE RELIEF | 3190 | 3190 | 3190 |
| TORO | LBS | AUX | PSI | HP | BOOM | ROC | WIDTH | HAMMER |
| 220 | 1430 | 10.8 | 3250 | 20 | RADIAL | 515 | E02, E04 | |
| 323 | 1567 | 10.8 | 3250 | 23 | RADIAL | 515 | E02, E04 | |
| 320D | 1722 | 10.8 | 3250 | 20 | RADIAL | 524 | E02, E04 | |
| E500 | 2342 | 6.5 | 3250 | RADIAL | 515 | E01, E02 | ||
| TX420 | 1880 | 11.2 | 3000 | 20 | RADIAL | 500 | E02, E04 | |
| TX427N | 1882 | 11.4 | 3000 | 25 | RADIAL | 535 | E02, E04 | |
| TX427W | 1990 | 11.4 | 3000 | 25 | RADIAL | 535 | E02, E04 | |
| TX525N | 1904 | 13.8 | 3000 | 23.3 | RADIAL | 553 | E02, E04 | |
| TX525W | 2013 | 13.8 | 3000 | 23.3 | RADIAL | 553 | E02, E04 | |
| TX700N | 2756 | 13.7 | 3000 | 24.5 | RADIAL | 700 | E02, E04 | |
| TX700W | 2862 | 13.7 | 3000 | 24.5 | RADIAL | 708 | E02, E04 | |
| TX1000N | 2610 | 15.2 | 3000 | 24.9 | VERTICLE | 1000 | E04 | |
| TX1000W | 2790 | 15.2 | 3000 | 24.9 | VERTICLE | 1000 | E04 | |
| TX1000N TURBO | 2826 | 13.2 | 3000 | 24.7 | VERTICLE | 1000 | E02, E04 | |
| TX1000W TURBO | 2911 | 13.2 | 3000 | 24.7 | VERTICLE | 1000 | E02, E04 | |
| TX1300 | 3858 | 13.4 | 3200 | 37 | 1300 | E02, E04 | ||
| TXL2000 | 6270 | 21.4 | 3000 | 49.6 | 2000 | |||
| TXL2000T | 6690 | 21.4 | 3000 | 49.6 | 2000 | |||
| BOBCAT | ||||||||
| MT50 | 2497 | 13.4 | 2600 | 18.8 | RADIAL | 500 | 35.6" | E02, E04 |
| MT52 | 2580 | 13.4 | 2900 | 20 | RADIAL | 520 | 35.6" | E02, E04 |
| MT55 | 2610 | 12 | 2900 | 12 | RADIAL | 550 | 35.6" | E02, E04 |
| MT85 | 3103 | 12 | 2900 | 12 | RADIAL | 850 | 35.6" | E02, E04 |
| MT100 | 3390 | 12 | 2900 | 12 | 1000 | 35.6" | E02, E04 | |
| DITCH WITCH | ||||||||
| C16X | ||||||||
| SK300 | ||||||||
| SK3000 | ||||||||
| SK350 | ||||||||
| SK500 | ||||||||
| SK600 | 2418 | 12 | 3000 | 24.8 | RADIAL | 600 | 33.5" | |
| SK650 | ||||||||
| SK750 | ||||||||
| SK752 | ||||||||
| SK755 | ||||||||
| SK800 | 2920 | 12 | 3000 | 24.8 | RADIAL | 911 | 36-42" | |
| SK850 | ||||||||
| SK900 | 3190 | 12 | 3000 | 24.8 | RADIAL | 932 | ||
| SK1050 | 3435 | 13.9 | 3625 | 37 | RADIAL | 1062 | 42 | |
| SK1550 | 4470 | 16 | 3700 | 43.5 | RADIAL | 1558 | 46.6 | |
| SK1750 | 4710 | 16 | 3700 | 43.5 | RADIAL | 1824 | 47 | |
| KUBOTA | ||||||||
| SCL1000 | 3035 | 15 | 2800 | 24.8 | VERTICLE | 1000 | E02, E04 | |
| KANGA | ||||||||
| PT220 | 1040 | 6.7 | 3000 | 20.8 | RADIAL | 357 | 31.1 | |
| PW220 | 980 | 6.7 | 3000 | 20.8 | RADIAL | 392 | 29.7 | |
| PW628 | 1965 | 10.75 | 3000 | RADIAL | 478 | 40.6 | ||
| DW625 | 2130 | 10.75 | 3000 | 23.5 | RADIAL | 527 | 40.6 | |
| PT728 | 1899 | 10.75 | 3000 | RADIAL | 426 | 40.9 | ||
| DT725 | 2075 | 10.75 | 3000 | 23.5 | RADIAL | 458 | 40.9 | |
| DT825 | ||||||||
| DW825 | ||||||||
| TR825 | ||||||||
| KRT | ||||||||
| S650 | 1984 | 15.3 | 23 | RADIAL | 500 | |||
| ST650 | 1984 | 15.3 | 23 | RADIAL | 500 | |||
| S900HD | 3306 | 16.5 | 24.8 | RADIAL | 1102 | |||
| ST900HD | 3527 | 16.5 | 24.8 | RADIAL | 1102 |
