CID Hydraulic Breakers for Excavators
$6,366.00 - $17,561.00
9-24
Hydraulic Breaker
The CID Hydraulic Breakers are the perfect attachment for rock, asphalt, or concrete demolition. Our Hydraulic Breakers are available in eight different models suitable for mini-skid steers, skid steers, compact loaders, and mini-excavators. CID also offers a variety of working tools for your Breaker: Cone points, Cross cut asphalt cutters, Inline Asphalt cutters, Asphalt cutters, Tamping tools, and Post drivers.
Model Specifications
- Longer Chisel Point and larger through bolt for added durability
- Stronger impact power, low noise design
- Control valve replaceable with ease and speed
- All Breakers include: Mount, Hoses, Moil Point, Blunt Point, Tool Kit, Nitrogen Gauge, and Operator’s Manual
- Two Year Warranty(Wear parts excluded)
- Auto Lube standard on four models, CBR1000 and above
- Additional Tool Tips available
|
Description |
Unit |
CBR225 | CBR500 | CBR650 | CBR850 | CBR1000 | CBR1200 | CBR2200 |
| Impact Energy Class | ft lb | 225 | 500 | 650 | 850 | 1000 | 1200 | - |
| Operation Weight | lb. | 269 | 419 | 618 | 772 | 1124 | 1245 | - |
| Hose Length | in. | .5"x90" | .5"x100" | .5"x100" | .75"x100" | .75"x100" | .75"x100" | - |
| Blow Rate | bpm long/s | 540~1000 | 600~1490 | 550~1300 | 380~1100 | 490~1100 | 480~1000 | - |
| Blow Rate | bpm short/s | - | - | - | - | 490~1100 | 480~1000 | - |
| Required Oil Flow | gpm | 3.96~7.92 | 5.2~10.5 | 7.9~17.1 | 10~21.1 | 10~23.7 | 11~25 | - |
| Operating Pressure | psi | 1280~1707 | 1280~1707 | 1565~2347 | 1707~2347 | 1991~2418 | 1991~2418 | - |
| Tool Diameter | in. | 1.77" | 2.24" | 2.75" | 2.95" | 3.14" | 3.54" | - |
| Accumulator Gas Pressure | psi | - | - | 570~710 | 570~710 | 570~710 | 570~710 | - |
| Suitable Carrier | ton | .8~2.5 | 1.5~4 | 3~6 | 4.5~8 | 4.5~8.8 | 6~10 | - |
| Suitable Carrier | lb. | 1600~5000 | 3000~8000 | 6000~12000 | 9000~16000 | 9000~17600 | 12000~20000 | - |
***Call for CBR2200 specifications
