Virnig V30 Compact Tractor Utility Fork Grapple (SSL) (CTL)

UGV48-CT / 9332PP

Virnig V30 Compact Tractor Utility Fork Grapple (SSL) (CTL)

$2,740.00

DESCRIPTION
SPECIFICATIONS

THIS ATTACHMENT INCLUDES

UNIVERSAL SKID STEER MOUNTING
HOSES, COUPLERS & FITTINGS

A durable, versatile one-cylinder grapple with replaceable tines.

1” diameter greaseable grapple pins.
Designed for easy cleanout and bulk material penetration.
Handles a variety of materials including manure, brush, and debris.
Corrosion, dent and flake resistant NitroSteel® cylinder rod made in the USA.
High tensile strength tines require no maintenance and are removable for easy replacement.
Light weight, yet durable construction perfect for compact tractors and small skid loaders.

Model	UGV8-CT	UGV54-CT	UGV60-CT	UGV66-CT	UGV72-CT
Overall Width (in)	49	54.5	60.5	66.5	72.5
Depth (in)	36.3	36.3	36.3	36.3	36.3
Height Overall (in)	28.2	28.2	28.2	28.2	28.2
Height Bucket (in)	20.5	20.5	20.5	20.5	20.5
Grapple Jaw Opening (in)	37.5	37.5	37.5	37.5	37.5
Number of Tines	7	8	9	10	11
Space Between Tines (in)	6.0	5.9	5.7	5.6	5.4
Tine Diameter (in)	1.5*	1.5*	1.5*	1.5*	1.5*
Cylinder Bore / Stroke (in)	1.25 / 8.0	1.25 / 8.0	1.25 / 8.0	1.25 / 8.0	1.25 / 8.0
Cylinder Pins / Hinge Pins Dia. (in)	1.0	1.0	1.0	1.0	1.0
Weight (lbs)	480	510	540	570	600
