SD45HPS-SPL300
5/24
Digga’s high powered augers operate at a maximum pressure 5,000psi, providing you with faster speed and performance - Without detuning your machine.
Gears are precision machined by Digga from high grade quality alloy steel, providing you with a highly efficient pressurized gearbox which ensures no leaks and minimal maintenance.
ensures max volumetric effeciency for consistent & efficient pile installation throughout the working day.
For maximum strength. Specifically designed for heavy duty drilling applications.
The Digga 2 piece shaft, is a separate component to the planetary carrier, isolating the planetary gears from the pushing, pulling & bending forces generated by the machine.
SPECS | SD45HPS | SD50HPS | SD70HPS | SD80HPS | SD95HPS |
MAX TORQUE (FT-LBS) | 33,654 | 39,463 | 51,634 | 62,638 | 69,244 |
MAX SPEED (RPM) | 46 | 39 | 30 | 25 | 22 |
MAX FLOW (GPM) | 100 GPM @ 3,500 PSI | ||||
MAX PRESSURE - DO NOT EXCEED | 5,000 PSI @70 GPM | ||||
MAX HORSE POWER | 201 | 201 | 201 | 201 | 201 |
MOTOR TYPE | RADIAL PISTON | RADIAL PISTON | RADIAL PISTON | RADIAL PISTON | RADIAL PISTON |
PRESSURE RELIEF VALVE | INCLUDED | INCLUDED | INCLUDED | INCLUDED | INCLUDED |
ENERGY CONTROL VALVE | NOT INCLUDED | NOT INCLUDED | NOT INCLUDED | NOT INCLUDED | NOT INCLUDED |
STANDARD OUTPUT SHAFT | 100MM SQUARE |
100MM SQUARE |
100MM SQUARE |
100MM SQUARE |
100MM SQUARE |
HALO | OPTIONAL | OPTIONAL | OPTIONAL | OPTIONAL | OPTIONAL |
RECOMMENDED AUGER | RC11 / DR11 | RC11 / DR11 | RC11 / DR11 | RC11 / DR11 | RC11 / DR11 |
MAX AUGER DIAMETER (CLAY / SHALE)* |
60" | 60" | 60" | 60" | 60" |
MAX AUGER DIAMETER (EARTH)* | 79" | 79" | 79" | 79" | 79" |
WEIGHT (LBS) | 1,843 | 1,843 | 1,843 | 1,843 | 1,843 |
OVERALL LENGTH (IN) | 50.9" | 50.9" | 50.9" | 50.9" | 50.9" |
DIAMETER (IN) | 23.6" | 23.6" | 23.6" | 23.6" | 23.6" |
