CB2000
Simex Crusher Buckets for skid steer loaders
$0.00 - $41,565.00
Designed for reduce the volume of aggregates directly on site, the CB crusher buckets for loaders and skid steers give optimal performance when working with iron, rock, soil and deformable parts, and wet or humid materials, thanks to the rotor system.
Ideal for crushing reinforced concrete and demolition waste. The exceptional cutting force allows any material to be crushed, without suffering the presence of rebar in it. The rotor with teeth is activated by high-displacement radial piston hydraulic motors in direct drive.
Advantages
- High cutting force
- Simple, quick tool replacement
- No vibrations
- Safe coupling and decoupling
- Replaceable blades for output size variation
- Lightweight frame
Features
Simex CB crusher buckets are available in 4 models (CB900-1200-1500-2000) for skid steers and front loaders.High cutting force
The exceptional cutting force allows any material to be crushed. The rotor with teeth is activated by high-displacement radial piston hydraulic motors in direct drive.
Ideal on concrete and waste material
Simex CB front crusher buckets are ideal for crushing and reduct waste material deriving from demolition, directly on site.
Easy tools replacement
The crushing tools easily interlock to the shaft with no weldings and are easily replaceable on site with no downtime due to long technical interventions.
unaffected by the presence of rebar
Crusher buckets can process reinforced concrete, unaffected by the presence of rebar in it.
Applications
The Simex CB crusher buckets for skid steers and front loaders are ideal when working on those sites where, due to space constraints or technical requirements, other machines would not be able to work, allowing to crush different types of materials such as reinforced concrete, bricks, wood, plasterboard, bricks and other aggregates resulting from demolition or construction.crushing demolition waste
Processing waste material from demolition and construction, the CB crusher bucket for front loaders finds its perfect situation. Instead of outsourcing the disposal processes, the operator can manage the volumetric reduction of the aggregates directly on site, producing a recycled material that can be used, for example, as stabilized aggregate for building development or in the road sector for the realization of embankments, back-fillings or yards.
| MODELS AND TECHNICAL DATA | °°° | CB 900 | CB 1200 | CB 1500 | CB 2000 |
|---|---|---|---|---|---|
| Total width |
mm |
1400 |
1500 |
1700 |
1900 |
| . |
inch |
55 |
60 |
67 |
75 |
| Rotor width |
mm |
700 |
840 |
965 |
1100 |
| . |
inch |
27 |
33 |
38 |
43 |
| Bucket capacity (SAE) |
m³ |
0,30 |
0,45 |
0,55 |
0,75 |
| . |
yd³ |
0,40 |
0,60 |
0,70 |
1,00 |
| Number of teeth |
n° |
5 |
6 |
7 |
8 |
| Bucket weight empty |
kg |
570 |
760 |
950 |
1150 |
| . |
lbs |
1250 |
1670 |
2090 |
2530 |
| Bucket weight at full load (1) |
kg |
900 |
1200 |
1500 |
2000 |
| . |
lbs |
1980 |
2640 |
3300 |
4400 |
| Required oil flow |
l/m |
40-80 |
70-150 |
70-150 |
70-150 |
| . |
gpm |
11-21 |
18-40 |
18-40 |
18-40 |
| Max. required oil pressure |
BAR |
300 |
350 |
350 |
350 |
| . |
psi |
4400 |
5100 |
5100 |
5100 |
