SA-15-SSL
ITEM/MODEL | SA-15MS | SA-15 | SA-30 | SA-40 |
TORQUE @3000 PSI | 1774 | 1774 | 2689 | 3110 |
MAX TORQUE @3500 PSI | 2070 | 2070 | 3137 | 3628 |
RECOMMENDED FLOW | 5-15 | 5-15 | 5-30 | 20-35 |
MOTOR TYPE | EATON | EATON | EATON | EATON |
MAX PRESSURE (PSI) | 3500 | 3500 | 3500 | 3500 |
MAX FLOW (GMP) | 15 | 15 | 30 | 35 |
STANDARD OUTPUT SHAFT | 2" HEX | 2" HEX | 2" HEX | 2" HEX |
DRIVE UNIT WEIGHT (LBS) | 160 | 125 | 125 | 130 |
OVERALL DRIVE UNIT LENGHT (IN) | 21" | 25" | 25" | 25" |
CARRIER WEIGHT | 1.5T - 3T | 1.5T - 3T | 2T - 5T | 4T - 8T |
CARRIER STYLE | MSSL | SSL/MX | SSL/MX | SSL/MX |
MAX AUGER DIAMETER | 24" | 24" | 36" | 36" |
