WBR04
Werk-brau Ripper shank for Mini excavators 1,500-4,900 lbs. (mini 04 & 05)
$1,500.00
9/25
Ripper Shank
Recommended Applications
Werk-Brau's Ripper is specifically engineered to pre-rip frozen ground, pavement, or other tough soil that exceeds a bucket's recommended duty. The Ripper is highly versatile attachment. The Ripper's single point tooth style is ideal for penetration of various tough environments.
Quality Construction
Werk-Brau uses T-1 steel in all critical or high wear components to ensure that the ripper has a long operation life. The ripper body is supported by rigid gussets for extra rugged applications. The upper gussets, and shank are designed for heavy duty applications in tough working conditions.
Cutting Equipment Options
A single point tooth is used to maximize the machine's penetrating power. A selection of high quality brands are available to choose from.
Standard Sizes
A selection of sizes are available to match each machine.
Additional Features
Dual ripper styles available. Different teeth available. Special designs are available.
| PART # | LENGTH | WIDTH | TOOTH | APPROX WEIGHT |
| WBR04 | 18" | 1" | (1) 8623 | 95 lbs. |
MINI 04
| MAKE / WEIGHT CLASS | MINI 04 (1,500 - 2,100 LBS.) |
| BOBCAT | 316 |
| CASE | |
| CAT | 300.9D |
| DOOSAN | S010 |
| DITCH WITCH | |
| GEHL | |
| HITACHI | ZX17U-2 |
| HYUNDAI | |
| IHI | 9NX-2 |
| JCB | MICRO 8008 |
| JOHN DEERE | |
| KOBELCO | |
| KOMATSU | PC09-1 |
| KUBOTA | K008 |
| LINK BELT | |
| MUSTANG | |
| NEW HOLLAND | |
| SANY | |
| TAKEUCHI | TB108 |
| VOLVO | |
| YANMAR | |
| WACKER NEUSON | 803 |
MINI 05
| MAKE / WEIGHT CLASS | MINI 05 (2,100 - 4,900 LBS.) |
| BOBCAT | 323 |
| CASE | CX17B |
| CAT | 301.5, 301.7CR, 301.8, 302CR |
| DOOSAN | S015 |
| DITCH WITCH | XT850 |
| GEHL | GE153 |
| HITACHI | EX17U |
| HYUNDAI | R16 |
| IHI | 15NX-2 |
| JCB | 8018 |
| JOHN DEERE | 17G |
| KOBELCO | 17SR |
| KOMATSU | PC18MR-3 |
| KUBOTA | KX018, U17 |
| LINK BELT | ME1503 |
| MUSTANG | E15, E18B |
| NEW HOLLAND | SY16 |
| SANY | TB016, TB216 |
| TAKEUCHI | EC15B |
| VOLVO | EC20B |
| YANMAR | Vio17, SV08-1, Vio20-3 |
| WACKER NEUSON | EZ17, 1404, ET20 |
